Ayrton Huracán Wash ST

CMY DMX 5 pin LED CW Quick trigger clamp RJ45 Shutter TRUE1 W-DMX

Product information

Ayrton has designed an entirely new Fresnel lens with an optical structure specially developed for use with framing barndoors, also favouring use with geometric gobos or ovalisation lenses, without constraints. A subtle progressive diffusion system allows the diffusion level to be adapted according to the application and accessories or optical elements used. The Fresnel lens also significantly improves the colour mix and can obtain 10% more light than when using a conventional Fresnel lens F.O.S.™. The proprietary optical system of Huracán Wash delivers a 12:1 zoom ratio and a zoom range of 6.2° at half peak to 75° at one-tenth peak. This new luminaire adopts the complex colour mixing system of Huracán profile, offering a double level of CMY saturation that can obtain 281 trillion colours and a triple corrector for variable colour temperature allowing subtle adjustment from 2700 K to 15000 K and significant CRI improvement. T.C.S.™.

Huracán Wash introduces a brand new 1000 W monochromatic LED source specially developed for studio and theatre applications, called the ST. This LED source delivers light output of 45,000 lumens and a D65 white point that allows perfect colour reproduction with a CRI greater than 80. Huracán Wash is factory-equipped with full features, including a framing section that allows accurate positioning of four barndoors on a 100% surface area in all positions, so that the user can frame any object regardless of the luminaire’s position. Huracán wash also offers a wheel of seven rotating gobos, a 15-blade iris diaphragm and a beam ovaliser filter.

Huracán Wash is an exceptional luminaire designed to satisfy the most demanding users.

  • 12:1 Zoom 6.2° (half peak) - 75° (one-tenth peak)
  • 210 mm Front Lens
  • Double CMY Mix
  • CTO
  • CTB
  • CTP
  • 6 complementary fixed colurs
  • Varible Frost 0-100%
  • 15-blade iris
  • 4 individually positonable barndoors
  • 7 indexable rotating gobos
  • CMY+RGB colur graphic animation effect-wheel
  • Advanced liquid cooling system


Fixture: Huracán Wash ST
Manufacture: Ayrton
Type: Wash
Source: 68,000 Lumen white LED-engine
Colour mixing: CMYx2 + CTO + CTB + CTP + 6 Fixed colour
CRI: 80
Color temperature: 6500 K
Output: 45,300 lm
Zoom: 6.2°-75° 12:1
Gobo: 7 rotating glass gobos + Open
Gobo Size: Gobo: 30.0 mm Image: 25.0 mm
Special: 4 positionable barndoors, Iris, CMY & RGB colour graphic animation effects-wheel
DMX: 5-pin In/ Out
DMX Channels: 37, 39, 61
Wireless DMX: CRMX TiMO RDM receiver
Network: RJ45 Ethercon In/ Out
Network Protocols: Art-Net, sACN
Power connection: Shucko -> Powercon True1
Power consumption: 1470 W
IP-class: Ip20
Weight: 42,5 kg
Dimensions (HxWxD): 78,8x29,4x49,4 cm
Colour: Black
