Blackmagic Design MC SDI-HDMI 3G w. PSU
Product information
The new Blackmagic Micro Converters are incredibly tiny broadcast video converters that let you connect between consumer HDMI and professional SDI equipment.
Supports all video standards in NTSC, PAL, 720 HD and 1080 HD
Supports 3G-SDI and HDMI timecode standards
With 3G-SDI technology and internal SDI reclocking
SDI video inputs: 1x for SD, HD or 3G-SDI
SDI video outputs: 1x loop-through output
HDMI output: 1x HDMI type A
Multirate support: Automatic detection of SD or HD
Details
| Product: | Micro Converter SDI-HDMI 3G w. PSU |
| Manufacture: | Blackmagic Design |
| Type: | Video converter |
| Local inputs: | 1x for SD, HD or 3G-SDI |
| Local outputs: | 1 x HDMI type A & 1x SDI loop-through output |
| Power connection: | Power supply: 4.4 - 5.25 V DC |
| Power consumption: | 1,6 W |
| Weight: | 0,15 kg |
| Dimensions (HxWxD): | 77 x 56 x 25 |
| Colour: | Grey |
