StageSmart SmartPDU C72tv

Stage Smart C72tv - made to be on tour!

The StageSmarts C72tv enables you to adapt your outputs to any situation with its quick-change modular output boxes. Change between different connector options in minutes depending on what’s needed for the client or fix a broken connector instantly during a show. The whole unit is protected in its custom flight case and floats freely in an integrated shock proof suspension system.

C72TV Features

• Seventy-two channels equipped with industrial-grade hydraulic-magnetic breakers
• Precise individual residual current detection on each output
• Thermal stability
• Extended usability due to seven auxiliary 16A Shucko outputs and  three 63A 3-phase output.
• Same high-grade breakers as in the rest of the unit but with separate adjustable residual current devices for the 3-phase outputs.
• Full remote access to all monitored data in real time over any standard network and on any device running a web browser
• Internal web server which allows naming of each unit, color-coding and naming of all channels.
• The status for the main-breaker, the E-stop, neutral protection and the unit’s internal temperature can also be monitored in the online interface.
• All settings automatically stored internally and travels with the unit
• Data can be imported and exported in standard excel-format.
• The onboard CPUs battery back-up ensures relevant information is provided during a total power failure to help you find and correct any problem rapidly.
• Available modules are Socapex for patching.

Technical Specifications

• Power input – Powerlock 400A | 5-wire (TN-S) 230/400V
• Main breaker – MCCB, electronic protection, 4-pole 400A
• Over-voltage protection – Immediate disconnection in case of lost neutral connection
• Main input metering – All incoming voltages, all currents (including neutral current), power factor, frequency
• Main status indicators – Multicolored status indicator
• Channel load monitoring – Individual status indicating multicolor LED
• No of main channels – 72
• Channel capacity and protection – 16A / channel, RCBO A-type, 30mA
• Auxiliary channel X0 – 2 parallel sockets (user seletable)
• Auxiliary capacity and protection – 16A / channel, RCBO A-type, 30mA
• Auxiliary channels X1-X6 – 16A, 3-pin CEE (customisable connectors)
• Auxiliary capacity and protection – 16A / channel, RCBO A-type, 30mA
• Auxiliary channels X7-X9 – 16A-63A, 5-pin CEE
• Auxiliary capacity and protection – 16A-63A, 4-pole breaker, adjustable and switchable RCD (30mA-5A) (20ms-5s)
• Main output connections – Modular
• Worklights – 4 x 3-pole XLR, 12VDC, 15W, PWM dimmer
• USB-charger – 5VDC, 2.1A
• Dimensions & weight – 1342 x 600 x 723mm, 150kg

Input:
400A Power-lock

Output:
Channels: 72 x 16A RCBO A-type 30mA
Outbreak: 24 Socapex outlet
3 x 63A CEE
6 x Shucko X1-X6
